DI-tech UXC-10S 10% Crosslinked Strong Acid Cation (Na+ form) Water Softener Resin
Major Applications the superior strength of DI-tech UXC-10S makes it an ideal candidate for:
- Industrial Softening (Na+ form)
- Industrial De-mineralization (H+ form)
- High TDS, high temperature softening
- Condensate Polishing
- Plating rinse metals scavenger
DI-tech Cation Series oxidation resistant, high temperature SOFTENING
UXC-10S & 10SB (black) 10% Crosslinked Strong Acid Cation (Na+ form)
Physical and Chemical Properties
| Polymer Structure | Styrene/ divinylbenzene 10% DVB gel | ||||||
| Functional Groups | Sulfonic Acid | ||||||
| Ionic Form as Shipped | Sodium (Na+) | ||||||
| Physical Form | Tough, spherical gold or black beads | ||||||
| Sphericity | 98% WPB | ||||||
| Total Capacity | 2.1 meq/ml (Na form) 45.3 Kgr/cu ft | ||||||
| Screen Size Distribution: | |||||||
| |||||||
| Uniformity Coefficient | 1.5 (max) | ||||||
| Moisture Content | 42-45% (Na+) | ||||||
| pH Range Stability | 0-14 | ||||||
| Temperature Limits | 150oC (300oF) Na form | ||||||
| Shipping Weight | 53 lbs per cubic foot | ||||||
| Packaging | 28.32 liter (1 cu ft) bags | ||||||
Chemical Stability
DI-tech UXC-10S is insoluble in moderately concentrated acids and bases. The highly cross-linked gel structure is very resistant to oxidizers such as peroxide, chlorine and ozone. UXC-10S can also operate at elevated temperatures and is well suited for hot water softening
UXC-10S & 10SB Fea t ures and Benefits
Major Applications the superior strength of DItech UXC-10S makes it an ideal candidate for:
Industrial Softening (Na+ form)
Industrial De-mineralization (H+ form)
High TDS, high temperature softening
Condensate Polishing
Plating rinse metals scavenger.
High Whole Bead Counts
DI-tech UXC-10Shas a 98% whole perfect bead count: lower pressure drop in service, no losses on backwash, more uniform flow distribution
Superior Physical & Oxidation Stability
The 98% plus sphericity and toughness of DI-tech UXC10S provides greater resistance to bead breakage with age and resists oxidation from chlorine, chloramine and other oxidants such as ozone and peroxide
Universal Utility
DI-tech UXC-10S and 10SB can be operated in the hydrogen (H+) form for de-mineralization service and demonstrates good oxidative resistance to chrome plating rinses. With higher cross-linking, DI-tech UXC-10S stands up to high temperature applications such as hot lime polishing and condensate polishing.
Safety Information
A material safety data sheet is available for DI-tech UXC-10S and 10SB. Copies can be obtained from Systematix Company (fax 714-522-5443). DI-tech UXC-10S is not a hazardous product and is not WHMIS controlled.
Caution: Acidic and basic regenerant solutions are corrosive and should be handled in a manner that will prevent eye and skin contact. Before using strong oxidizing agents in contact with ion exchange resin, consult sources knowledgeable in the handling of these materials.
